W-axis reducer: Alpha (Germany)

• Rated torque: 167.3N.m

• Instantaneous max. torque: 585.2N.m

• Rated speed: 43 rpm (Max: 85 rpm)

B-axis reducer: Alpha (Germany)

• Rated torque: 88.9N.m

• Instantaneous max. torque: 312N.m

• Rated speed: 43 rpm (Max: 85 rpm)

C-axis reducer: Alpha (Germany)

• Rated torque: 88.9N.m

• Instantaneous max. torque: 312N.m

• Rated speed: 43 rpm (Max: 85 rpm)

Z2 axis & Transmission components: Rexroth (Germany)

• Repeatability: ±0.005mm

Main Spindle (Electric)

• Power: 3.7kw

• Max. speed: 40000 rpm

• Cooling: Water cooling with flow-alarm

8th axis second spindle (Electric)

• Power: 4.0kw

• Max. speed: 26000 rpm

• Features: 6 additional tools; round cutter dia. 40mm–70mm

Tool Magazine (Servo-drive)

• Capacity: Up to 15 tools for vertical main spindle

• Tool holder specification: ISO 20

• Chuck specification: ER 16

• Tool clamping range: $\Phi$1mm–$\Phi$10mm

Operation & Control

• System: SYNTEC system

• Interface: 220MB-E5 inch screen operation box

• Servo motor power: 200W / 400W / 750W

Physical & Accuracy Specs

• XX2YZ stroke: 380 * 40 * 70 * 120

• Repeat positioning accuracy: ±0.005mm

• Working flatness: ±0.005mm

• Boundary Dimensions: 1300 * 1600 * 2050

• Body weight: 1.7 tons

• Power configuration: 380v/50hz
