PL3000-MJP 3-Printhead Wax Printer

PL3000-MJP 3-Printhead Wax Printer

  • Build volume (X × Y × Z): 294 × 212 × 138 mm

  • Resolution (X × Y × Z): 1200 × 1200 × 1600 dpi (3200 dpi at 8 µm / 1600 dpi at 16 µm)

  • Accuracy: ±0.08 mm per 20 mm of part dimension

  • Slicing software: PL3DPrint

  • File format: STL, SLC, OBJ

  • Material package:

    • Build material: 3 kg/bottle

    • Support material: 3.6 kg/bottle

    • Maximum capacity: 2 build & 2 support bottles

  • Machine size: 1310 × 770 × 1670 mm

  • Machine weight: Gross: 630 kg, Net: 480 kg

  • Current and voltage: 220–240V AC, 50/60Hz, 23A

  • Input/Output: 220–240V AC, 50Hz, 10A, Single C14 socket

  • Warranty: 1 year

Share This Items :

Description

  1. High-efficiency wax printing: Designed for fast and continuous operation, significantly improving printing speed and production efficiency.

  2. Three-printhead system: Equipped with 3 independent printheads, enabling higher output, improved stability, and consistent wax model production.

  3. High-precision printing: Delivers accurate dimensions, smooth surfaces, and fine details, meeting high-standard requirements for wax pattern manufacturing.

  4. Uniform printing quality: Ensures consistent layer thickness and excellent surface finish, reducing post-processing and material waste.

  5. Wide application range: Ideal for producing wax models used in jewelry casting, precision investment casting, and industrial prototyping.

  6. Automatic control system: Features an advanced intelligent control system with a simple and user-friendly UI interface, allowing easy operation and precise parameter adjustment.

  7. Stable and reliable design: Built with a rigid structure and multiple safety and protection systems, ensuring safe, stable, and reliable long-term operation.
